Overview：The high-speed centrifugal spray device for traditional Chinese medicine extract is the application of centrifugal spray drying technology in the drying of specific materials.
Consulting
product description
The machine adopts a fully enclosed form, all parts are made of stainless steel, equipped with a three-stage purification device, and the filtered air reaches the level of 100,000. The cylinder and the top are equipped with cold wall devices, so that the wall temperature is less than 80 ℃, and the drying tower is equipped with an air brush sweeping tower device. The traditional Chinese medicine extract powder dried by this machine will not show the phenomenon of coking and deterioration, greatly increase the powder collection rate (more than 95%), and will not produce mixing phenomenon and wall sticking phenomenon.
working principle
The high-speed centrifugal spray device for traditional Chinese medicine extract is the application of centrifugal spray drying technology in the drying of specific materials. It also uses a high-speed centrifugal atomizer to disperse the materials into mist, fully contact with hot air, and complete instant drying to form a powdery product.
The drying device.
Performance characteristics
◎The tower body has a cold wind jacket;
◎The tower body is equipped with an automatic rapping device;
◎The tower body and pipeline are equipped with quick-open cleaning holes and drain holes;
◎It can be equipped with automatic control constant temperature feeding tank;
◎Can be equipped with manual high-pressure washing tower accessories;
◎The part in contact with the material is made of stainless steel; (or all stainless steel);
◎Material collection adopts two-stage cyclone dust removal device, or one-stage
◎Cyclone dust collector and wet dust collector;
◎The inlet air temperature realizes automatic control and continuous device.
◎Can be equipped with air sweep device.
Technical specifications
| model | ZLPG-15 | ZLPG-20 | ZLPG-25 | ZLPG-32 | ZLPG-38 | ZLPG-40 | ZLPG-47 | ZLPG-52 | ZLPG-58 | |
| Water evaporation | 5 | 10 | 25 | 50 | 80 | 100 | 150 | 200 | 300 | |
| Material liquid handling capacity | 6-7 | 12-14 | 25-34 | 50-68 | 80-108 | 100-135 | 150-203 | 200-270 | 300-406 | |
| Finished product output | 1-2 | 2-4 | 4.8-7.2 | 9.2-14 | 14.8-22.4 | 18.4-28 | 28-42 | 36.8-56.4 | 55-85 | |
| Solid content of wet material | 18-25 | |||||||||
| Finished water content | 3-5 | |||||||||
| Electric power | 36 | 45 | 63 | 99 | 132 | 153 | 204 | 246 | 330 | |
| Heating source | Steam + electricity | |||||||||
|
Product collection method And one-time collection efficiency |
One or two points collection: collect BMX ≥95% at one time | |||||||||
| Automatic control instrument | Automatic control and adjustment of temperature and pressure, interlocking alarm | |||||||||
| Inlet air temperature | 150-200 | |||||||||
| Outlet temperature | 80-100 | |||||||||
| Dimensions(mm) | long | 5000 | 5500 | 7000 | 8000 | 9800 | 11000 | 12200 | 14100 | 15000 |
| width | 3000 | 3500 | 4000 | 5000 | 5700 | 6200 | 7000 | 7800 | 9000 | |
| high | 4500 | 4600 | 5200 | 6500 | 7600 | 8100 | 9000 | 9850 | 11100 | |
Note: ★The actual dimensions can be determined according to the actual situation of the customer, the above dimensions are for reference only.
★The above evaporation capacity is the upper limit of evaporation capacity.
