Overview：The SZH series double cone mixer transfers powder or granular materials into the double cone container by vacuum conveying or manual feeding. With the continuous rotation of the volume,
ConsultingPerformance characteristics
◎This machine transfers powder or granular materials into a double cone container by vacuum conveying or manual feeding. With the continuous rotation of the container, the materials undergo complex impact movement in the container to achieve uniform mixing.
◎This machine saves energy, is easy to operate, low labor intensity, and high work efficiency.
Adapt to materials
◎This machine is suitable for mixing powdery and granular materials in the pharmaceutical, chemical, food, and building materials industries.
Technical specifications
| Specifications\Project |
Total volume L |
Working volume L |
Feeding amount kg |
Feeding speed rpm |
power kw |
weight kg |
| 0.05 | 50 | 25 | 15 | 25 | 0.55 | 500 |
| 0.15 | 150 | 75 | 45 | 20 | 0.75 | 650 |
| 0.3 | 300 | 150 | 90 | 20 | 1.1 | 820 |
| 0.5 | 500 | 250 | 150 | 18 | 1.5 | 1250 |
| 1 | 1000 | 500 | 300 | 15 | 3 | 1800 |
| 1.5 | 1500 | 750 | 450 | 12 | 4 | 2100 |
| 2 | 2000 | 1000 | 600 | 12 | 5.5 | 2450 |
| 3 | 3000 | 1500 | 900 | 9 | 5.5 | 2980 |
| 4 | 4000 | 2000 | 1200 | 9 | 7.5 | 3300 |
| 5 | 5000 | 2500 | 1500 | 8 | 7.5 | 3880 |
| 6 | 6000 | 3000 | 1800 | 8 | 11 | 4550 |
| 8 | 8000 | 4000 | 2400 | 6 | 15 | 5200 |
| 10 | 10000 | 5000 | 3000 | 6 | 18.5 | 6000 |
